**1 YEAR WARRANTY**
The A-2200IEH-XR is up to the challenge of lifting all ATVs on the market today. In addition to the new and innovative retractable ramp system the A-2200IEH-XR has pivot approach ramps that fold out of the way as the lift raises and become wheels stops. Keeping the technician in mind these features limit injury, save time and space which makes your shop area more productive. Our single point hand held pendant fully controls the lift; lifting, lowering into locks and lowering without the use of hands or feet to disengage manual safety latches.
Features
NEW! Retractable Ramp System
NEW! Pivot Approach Ramps
47" Rise Height
110V Integrated Electric/Hydraulic Power Unit
Hand Held Control Pendant Six Locking Positions
Extended 27.5" Long Full Width Approach Ramp
50" X 88.6" Table
Optional: Vise, Chock, Dolly Kit
Specifications
Capacity: 2,200 lbs.
Lifting Height: Max: 47.2”
Height, Min: 7”
Platform Width: 50” (Main Table 31.5"W Side Extensions 9.25" Each)
Length Overall: 116.5” -Fully Lowered
Platform Length: 88.6”
Width Overall: 58.5” (Base Frame + Stabilizer Bar)
Power Supply: 110V, 60Hz, 1 Phase, 18A
Lifting Time: 30S
Lowering Time: 30 S
Gross Weight: 980 lbs.
Electro-Hydraulic/ ATV Lift Bench with Retractable Ramp Manual
